Dasan V5808 - Configuring Admin Flow

UMN:CLI User Manual
V5808
194
Command
Mode
Description
flow admin NAME create
Global
Creates an admin flow and opens Admin-Flow
Configuration mode.
NAME: admin-flow name.
After opening Admin-Flow Configuration mode, the prompt changes from
SWITCH(config)# to SWITCH(config-admin-flow[NAME])#.
To delete configured admin flow or all admin flows, use the following command.
Command
Mode
Description
no flow admin NAME
Global
Deletes specified admin flow.
no flow admin all
Deletes all admin flows.
After opening Admin-Flow Configuration mode, an admin flow can be configured by user.
The packet classification can be configured for each admin-flow.
• The admin-flow name must be unique. Its size is limited to 32 significant characters.
• The admin-flow name cannot start with the alphabet “a” or “A”.
• The order in which the following configuration commands are entered is arbitrary.
• The configuration of a flow being configured can be changed as often as wanted
until the apply command is entered.
• Use the show flow-profile admin command to display the configuration entered up
to now.
7.5.6.2 Configuring Admin Flow
You can classify the packets according to IP address, ICMP, TCP, UDP and IP header
length. To specify a packet-classifying pattern, use the following command.
Command
Mode
Description
ip {A.B.C.D | A.B.C.D/M | any}
{A.B.C.D | A.B.C.D/M | any} [0-
255]
Admin-Flow
Classifies an IP address:
A.B.C.D: source/destination IP address
A.B.C.D/M: source/destination IP address with mask
any: any source/destination IP address
0-255: IP protocol number
ip {A.B.C.D | A.B.C.D/M | any}
{A.B.C.D | A.B.C.D/M | any} icmp
Classifies an IP protocol (ICMP):
A.B.C.D: source/destination IP address
A.B.C.D/M: source/destination IP address with mask
any: any source/destination IP address
ip {A.B.C.D | A.B.C.D/M | any}
{A.B.C.D | A.B.C.D/M | any} icmp
{<0-255> | any} {<0-255> | any}
Classifies an IP protocol (ICMP):
A.B.C.D: source/destination IP address
A.B.C.D/M: source/destination IP address with mask
any: any source/destination IP address
0-255: ICMP message type number
0-255: ICMP message code number
ip {A.B.C.D | A.B.C.D/M | any}
{A.B.C.D | A.B.C.D/M | any} {tcp |
Classifies an IP protocol (TCP/UDP):
A.B.C.D: source/destination IP address
i
