11.3.2 ABR Type Configuration
The V5808 supports 3 types of OSPFv3 ABR which are Cisco type ABR (RFC 3509), IBM
type ABR (RFC 3509), and standard RFC 2328 type.
To configure ABR type of OSPFv3, use the following command.
abr-type {cisco | ibm | standard}
Selects an ABR type.
cisco: cisco type ABR, RFC 3509 (default)
ibm: IBM type ABR, RFC 3509
standard: RFC 2328 type
Deletes a configured ABR type.
11.3.3 OSPFv3 Interface
OSPFv3 configuration can be changed. Users are not required to alter all of these
parameters, but some interface parameters must be consistent across all routers in an
attached network.
11.3.3.1 Interface Cost
OSPFv3 protocol assigns suitable cost according to the bandwidth on the each interface
to find the shortest route. The cost is used for packet routing, and routers are using the
Cost to communicate.
To set an interface cost for OSPFv3, use the following command.
Configures an interface cost for OSPFv3
ipv6 ospf cost <1-65535>
instance-id <0-255>
To delete a configured interface cost for OSPFv3, use the following command.
Deletes a configured an interface cost for OSPFv3.
no ipv6 ospf cost instance-id
<0-255>
11.3.3.2 Routing Protocol Interval
The following lists are sort of time interval which can be configured by user:
• Hello Interval
OSPFv3 router sends Hello packet to notify existence of itself. Hello interval is that
packet transmission interval.
