12.3.2.14 Applying Traffic & PM Profile
To add/delete the user-defined Traffic profile to a specified ONU profile, use the following
command.
Adds the existing Traffic profile to ONU profile.
NAME: Traffic profile name
Removes the Traffic profile from ONU profile.
For the details of how to create and configure the traffic profile, see 12.4 Traffic Profile.
To add/delete the user-defined PM profile to a specified ONU profile, use the following
command.
Adds the existing PM profile to ONU profile.
NAME: Traffic profile name
Removes the PM profile from ONU profile.
For the details of how to create and configure the PM profile, see 12.10 Performance
Monitoring (PM) Profile.
12.3.3 Overwriting Traffic Profile Configuration
Basically, one traffic profile can be applied to the ONU profile. So, if a number of cases for
traffic profile configuration are required on the ONU profile, the user should create the
corresponding traffic profiles and apply them to the ONU profile.
The overwriting traffic profile configuration can help reducing the count of creating and
applying the traffic profile. This configuration overwrites the corresponding setting of the
applied traffic profile.
12.3.3.1 VLAN Configurations
To configure a VLAN tagging operation for a specific UNI port, use the following
command.
uni eth UNI-PORT vlan-operation
us-oper keep
Sets the policy of VLAN tagging for upstream frame.
keep: keeps forwarding the existing tagged/untagged
frame
uni eth UNI-PORT vlan-
operation us-oper {add |
overwrite} <1-4094> <0-7>
Sets the policy of VLAN tagging for upstream frame.
add: adds a specified VID (double tagging) with tag in
case of tagged frame
overwrite: replaces an existing tagged/untagged frame
