12.8.7.1 Clock Reference
To specify the frequency of the common timing reference, use the following command.
rtp-clock-reference VALUE
Specifies the frequency of the common timing
reference.
VALUE: in multiples of 8 kHz (for example, input 1
means 8 kHz) (default: 1)
12.8.7.2 RTP Time Stamp Mode
To specify the RTP time stamp mode, use the following command.
rtp-time-stamp-mode {unknown |
absolute | differential}
Determines the mode in which RTP timestamps are
generated in the TDM to PSN direction.
unknown: Unknown or not applicable (default)
absolute: Absolute. Timestamps are based on the
timing of the incoming TDM signal
differential: Differential. Timestamps are based on the
ONT's reference clock, which is understood to be
stratum-traceable along with the reference clock at the
far end
12.8.7.3 RTP Payload Type
To configure the RTP payload type, use the following command.
rtp-payload-type payload VALUE
signalling VALUE
Specifies the RTP payload type in the TDM to PSN
direction.
payload VALUE: for the payload channel
signalling VALUE: 96 to 127, for the optional separate
signalling channel. If signalling is not transported in its
own channel, this value should be set to 0.
rtp-expect-payload-type payload
VALUE signalling VALUE
Specifies the RTP payload type in the PSN to TDM
direction. The received payload type may be used to
detect malformed packets.
payload VALUE: for the payload channel
signalling VALUE: for the optional separate signalling
channel
no rtp-expect-payload-type
Deletes the configured RTP payload type in the PSN to
TDM direction.
