To delete the configured one-to-one VLAN mapping and translation, use the following
command.
Command
Mode
Description
no vlan dot1q-tunnel ingress mapping PORTS
c-vid <1-4094> trans-s-vid
Bridge
Deletes the configured 1:1 VLAN
mapping and translation.
no vlan dot1q-tunnel egress mapping PORTS
s-vid <1-4094> trans-c-vid
no vlan dot1q-tunnel ingress range-mapping
PORTS c-vid <1-4094> trans-s-vid
no vlan dot1q-tunnel {ingress | egress}
mapping PORTS s-vid <1-4094> trans-s-vid
no vlan dot1q-tunnel ingress range-mapping
PORTS s-vid <1-4094> trans-s-vid
8.1.9.3 One-to-Two VLAN Mapping between S-VID and C-VID
To configure one-to-two VLAN mapping and translation, use the following command.
Command
Mode
Description
vlan dot1q-tunnel ingress
mapping PORTS s-vid <1-4094>
trans-s-vid <1-4094> trans-c-vid
<1-4094>
Bridge
Configures 1:2 VLAN mapping for NNI port and
translates incoming Single Outer Tagged (SOT) packet
with given S-VLAN tag to Double Tagged (DT) packet
by adding S-VLAN and C-VLAN tags.
PORTS: NNI port number
vlan dot1q-tunnel egress
mapping PORTS s-vid <1-4094>
trans-s-vid <1-4094> trans-c-vid
<1-4094>
Configures 1:2 VLAN mapping for NNI port and
translates outgoing Single Outer Tagged (SOT) packet
with given S-VLAN tag to Double Tagged (DT) packet
by adding S-VLAN and C-VLAN tags.
PORTS: NNI port number
vlan dot1q-tunnel ingress range-
mapping PORTS s-vid <1-4094>
trans-s-vid <1-4094> trans-c-vid
<1-4094>
Configures 1:2 VLAN mapping for NNI port and
translates incoming Single Outer Tagged (SOT) packet
in the given S-VLAN range to Double Tagged (DT)
packet by adding S-VLAN and C-VLAN tags.
To delete the configured one-to-two VLAN mapping and translation, use the following
command.
Command
Mode
Description
no vlan dot1q-tunnel ingress
mapping PORTS s-vid <1-4094>
trans-s-vid trans-c-vid
Bridge
Deletes the configured 1:2 VLAN mapping and
translation.
no vlan dot1q-tunnel egress
mapping PORTS s-vid <1-4094>
