Dasan V5808 - Double Tagging Operation; Double Tagging Configuration

UMN:CLI User Manual
V5808
272
To delete the configured two-to-two VLAN mapping and translation, use the following
command.
Command
Mode
Description
no vlan dot1q-tunnel ingress
mapping PORTS internal s-vid
<1-4094> c-vid <1-4094>
Bridge
Deletes the configured 2:2 VLAN mapping and
translation.
no vlan dot1q-tunnel egress
mapping PORTS external s-vid
<1-4094> c-vid <1-4094>
8.1.9.6 Double Tagging Operation
Step 1
If there is no SPVLAN Tag on received packet, SPVLAN Tag is added.
SPVLAN Tag = TPID : Configured TPID
VID : PVID of input port
Step 2
If a received packet is tagged with CVLAN, the switch transmits it to uplink port changing
to SPVLAN + CVLAN. When TPID value of received packet is same with TPID of port, it
recognizes as SPVLAN, and if not as CVLAN.
Step 3
If Egress port is Access port (Access port is configured as Untagged), remove SPVLAN. If
egress port is uplink port, transmit as it is.
Step 4
The V5808 switch has 0x8100 TPID value as default and other values are used as
hexadecimal number.
8.1.9.7 Double Tagging Configuration
Step 1
Designate the QinQ port.
Command
Mode
Description
vlan dot1q-tunnel enable PORTS
Bridge
Configures a qinq port.
PORTS: qinq port to be enabled
Step 2
Configure the same PVID with the VLAN of peer network on the designated qinq port.
Command
Mode
Description
vlan pvid PORTS <1-4094>
Bridge
Configure a pvid.
PORTS: qinq port to be enabled
1-4094: PVID
