Dasan V5808 - RTP Synchronization Source; Pseudowire Maintenance Configuration; Saving TDM Pseudowire Profile

UMN:CLI User Manual
V5808
772
12.8.7.4 RTP Synchronization Source
To configure the RTP synchronization source, use the following command.
Command
Mode
Description
rtp-sync-source payload VALUE
signalling VALUE
TDM-PW-
Profile
Specifies the RTP synchronization source in the TDM
to PSN direction.
payload VALUE: for the payload channel
signalling VALUE: for the optional separate signalling
channel. If signalling is not transported in its own
channel, this value should be set to 0.
rtp-expect-sync-source payload
VALUE signalling VALUE
Specifies the RTP synchronization source in the PSN
to TDM direction. The received synchronization source
may be used to detect misconnection (stray packets).
payload VALUE: for the payload channel
signalling VALUE: for the optional separate signalling
channel
no rtp-expect-sync-source
Deletes the configured RTP synchronization source in
the PSN to TDM direction.
12.8.8 Pseudowire Maintenance Configuration
If you need the configuration for pseudowire service exception handling, you should
connect a pseudowire maintenance profile to the current profile.
To connect the pseudowire maintenance profile to the current profile, use the following
command.
Command
Mode
Description
pw-maintenance-profile NAME
TDM-PW-
Profile
Connects a pseudowire maintenance profile to the
current TDM pseudowire profile.
no pw-maintenance-profile
Disconnects the specified pseudowire maintenance
profile.
For the details of how to create and configure the pseudowire maintenance profile, see
12.9 Pseudowire Maintenance Profile.
12.8.9 Saving TDM Pseudowire Profile
After configuring a TDM pseudowire profile, you need to save the profile with the following
command.
Command
Mode
Description
apply
TDM-PW-
Profile
Saves a TDM pseudowire profile configuration.
Whenever you modify a TDM pseudowire profile, you should apply the changes again
using the apply command. If not, the changes will not be applied.
