User Manual UMN:CLI
V5808
779
12.10 Performance Monitoring (PM) Profile
Performance Monitoring (PM) profile is used for the traffic statistics of all ONUs (ONTs)
collected by an OLT. The ONT conceptually has only two storage bins: a current
accumulator and a history bin. The current accumulator is used to store data collected for
the current 15-minute interval. The history bin is used to store data for the previous 15-
minute interval. At the end of the current 15-minute interval, they switch roles: the
previous accumulator bin becomes the new history bin, while the content of the history
bin is discarded and the bin itself is initialized as the new accumulator.The ONT performs
no calculations upon the collected data nor does it keep an archive of collected data
beyond the previous 15-minute interval. All calculations based on collected data and
archiving of past intervals is performed by the OLT.
12.10.1 Creating PM Profile
To create a PM profile, use the following command.
Creates a PM profile.
NAME: PM profile name
To delete a created PM profile, use the following command.
no pm-profile {NAME | all}
Deletes a created PM profile.
NAME: PM profile name
To modify an existing PM profile, use the following command.
Modifies the existing PM profile.
NAME: PM profile name
To collect the traffic statistics of ONUs via PM profile, the ONU must be applied with a
Traffic Profile.
12.10.2 Collecting ONU Traffic Statistics
To enable/disable the performance monitoring (PM) function to collect the traffic statistics
of the configured GEM port, use the following command.
Enables the PM function to collect the GEM port-
related counters.
Disables the PM function to collect the GEM port-
related counters.
