PIR_VALUE: PIR bandwidth range of 0 to 2147483584
no gemport GEM-PORT-RANGE
rate-limit { upstream |
downstream }
Deletes the configured rate limit of GEM port ID.
You should configure GEM port count for mapper before setting the rate limit for GEM
port.
To apply the configured Rate-limit profile for GEM ports, use the following command.
Command
Mode
Description
gemport RANGE rate-limit
profile NAME
Traffic-
Mapper
Applies the configured Rate-limit profile to specified
GEM port.
NAME: Rate-limit profile name
no gemport RANGE rate-limit
profile
Removes the Rate-limit profile from the GEM port.
For the details of how to create and configure the Rate-limit profile, see 12.12 Rate-limit
Profile.
12.4.3 MAC Bridge Service Profile
A MAC bridge service profile can be configured per each UNI-side port or it can be
configured for the multiple UNI-side ports.
The MAC bridge service profile is comprised of ANI-side port for the upstream traffic
management and UNI-side port for the downstream traffic management. The system
creates both ANI-side and UNI-side MAC bridge port config data ME.
To create a bridge ID and open a MAC Bridge Service Profile Configuration mode, use
the following command.
Command
Mode
Description
bridge BRIDGE_ID
Traffic-
Profile
Creates a bridge ID in traffic profile.
BRIDGE_ID: 1 to 32, MAC Bridge ID
After opening MAC Bridge Service Profile Configuration mode, the prompt changes from
SWITCH(gpon)# to SWITCH(config-traffic-pf[NAME]-bridge[BRIDGE_ID])#.
To remove the configured bridge ID from a traffic profile, use the following command.
Command
Mode
Description
no bridge BRIDGE_ID
Traffic-
Profile
Removes the configured bridge ID from a traffic profile
