Dasan V5808 - VLAN Tagging Operating

UMN:CLI User Manual
V5808
720
command.
Command
Mode
Description
vlan-filter [vid <1-4094>]
untagged {allow | discard}
Traffic
Bridge-UNI
Enables a VLAN tagging filtering function of UNI-side
port.
allow: forwards the untagged frames to UNI-side port
discard: blocks the untagged frames to UNI-side port
1-4094: VLAN ID(s)
vlan-filter vid {add | del} VID
Adds or deletes the VLAN ID on the VLAN list
configured by vlan-filter vid command above.
VLAN Tagging Operating
To configure a VLAN tagging operation, use the following command.
Command
Mode
Description
vlan-operation us-oper keep
Traffic
Bridge-UNI
Sets the policy of VLAN tagging for upstream frame.
keep: keeps forwarding the existing tagged/untagged
frame
vlan-operation us-oper {add |
overwrite} <1-4094> <0-7>
Sets the policy of VLAN tagging for upstream frame.
add: adds a specified VID (double tagging) with tag in
case of tagged frame
overwrite: replaces an existing tagged/untagged frame
to a specified VID with tag.
1-4094: VLAN ID
0-7: CoS value
vlan-operation ds-oper {keep |
remove}
Sets the policy of VLAN tagging for downstream frame.
keep: keeps forwarding the incoming tagged frame
from OLT to UNI.
remove: removes a tag from the incoming tagged
packet and forwards it to UNI.
no vlan-operation
Deletes the configured policy for VLAN tagging
operation.
Rate Limit
To configure the rate limit for an UNI-side port of ONU, use the following command.
Command
Mode
Description
rate-limit {upstream |
downstream} PIR_BANDWIDTH
SIR_BANDWIDTH
Traffic
Bridge-UNI
Sets the downstream/upstream traffic bandwidth for
UNI port.
SIR_BANDWIDTH: 0 to 2147483584 (in steps of
64Kbps)
PIR_BANDWIDTH: 0 to 2147483584
no rate-limit {upstream |
downstream}
Deletes the configured rate limit.
To apply the configured Rate-limit profile for an UNI-side port of ONU, use the following
command.
