Dasan V5808 - IGMP Snooping Query Response Time; Displaying IGMP Snooping Querier Information

UMN:CLI User Manual
V5808
418
ip igmp snooping querier query-
interval <1-1800>
Global
Specifies an IGMP snooping query interval in the unit
of second.
1-1800: query interval (default: 125)
ip igmp snooping vlan VLANS
querier query-interval <1-1800>
Specifies an IGMP snooping query interval on a VLAN.
VLANS: VLAN ID (1-4094)
To delete a specified interval to send general query messages, use the following
command.
Command
Mode
Description
no ip igmp snooping querier
query-interval
Global
Disables a specified IGMP snooping query interval.
no ip igmp snooping vlan
VLANS querier query-interval
IGMP Snooping Query Response Time
Membership query messages include the maximum query response time field. This field
specifies the maximum time allowed before sending a responding report. The maximum
query response time allows a router to quickly detect that there are no more hosts
interested in receiving multicast traffic.
To specify a maximum query response time advertised in general query messages, use
the following command.
Command
Mode
Description
ip igmp snooping querier max-
response-time <1-25>
Global
Specifies a maximum query response time.
1-25: maximum response time (default: 10 seconds)
ip igmp snooping vlan VLANS
querier max-response-time <1-
25>
Specifies a maximum query response time.
VLANS: VLAN ID (1-4094)
To delete a specified maximum query response time, use the following command.
Command
Mode
Description
no ip igmp snooping querier
max-response-time
Global
Deletes a specified maximum query response time.
no ip igmp snooping vlan
VLANS querier max-response-
time
Displaying IGMP Snooping Querier Information
To display IGMP querier information and configured parameters, use the following
command.
