9.2.6 Multicast VLAN Registration (MVR)
Multicast VLAN registration (MVR) is designed for applications using multicast traffic
across an Ethernet network. MVR allows a multicast VLAN to be shared among
subscribers remaining in separate VLANs on the network. It guarantees the Layer 2
multicast flooding instead of the forwarding via Layer 3 multicast, allowing to flood
multicast streams in the multicast VLAN, but to isolate the streams from the subscriber
VLANs for bandwidth and security reasons. This improves bandwidth utilization and
simplifies multicast group management.
MVR also provides the fast convergence for topology changes in the Ethernet ring-based
service provider network with STP and IGMP snooping TCN, guaranteeing stable
multicast services.
MVR implemented for the V5808 has the following restrictions, so you must keep in mind
those, before configuring MVR.
• All receiver ports must belong to the both subscriber and multicast VLANs as un-
tagged.
• IGMP snooping must be enabled before enabling MVR.
• A single group address cannot belong to more than two MVR groups.
• MVR and multicast routing cannot be enabled together.
• MVR only supports IGMPv2.
9.2.6.1 Enabling MVR
To enable MVR on the system, use the following command.
9.2.6.2 MVR Group
To configure MVR, you need to specify an MVR group and group address. If you specify
several MVR groups, IGMP packets from the receiver ports are sent to the source ports
belonging to the corresponding MVR group according to the group address specified in
the packets.
To specify an MVR group and group address, use the following command.
mvr vlan VLAN group A.B.C.D
Specifies an MVR group and group address.
VLAN: VLAN ID (1-4094)
A.B.C.D: IGMP group address
no mvr vlan VLAN group A.B.C.D
Deletes a specified MVR group and group address.
