Dasan V5808 - Basic Service Type; Signalling; Payload Size

User Manual UMN:CLI
V5808
769
12.8.2 Basic Service Type
To specify the basic service type, use the following command.
Command
Mode
Description
service-type {unstructured |
octet-aligned-unstructured |
structured}
TDM-PW-
Profile
Specifies the basic service type, either a transparent bit
pipe or an encapsulation that recognizes the underlying
structure of the payload.
unstructured: Basic unstructured (also known as
structure agnostic)
octet-aligned-unstructured: Octet-aligned unstructured,
structure agnostic. Applicable only to DS1, a mode in
which each frame of 193 bits is encapsulated in 25
bytes with 7 padding bits
structured: Structured (structure-locked)
12.8.3 Signalling
To configure the signalling, use the following command.
Command
Mode
Description
signalling { no-signalling | cas-
carry-packet | cas-carry-
channel }
TDM-PW-
Profile
Specifies the signalling attribute.
no-signalling: No signalling visible at this layer
cas-carry-packet: CAS, to be carried in the same
packet stream as the payload
cas-carry-channel: CAS, to be carried in a separate
signalling channel
12.8.4 Payload Size
To specify the payload size per packet, use the following command.
Command
Mode
Description
payload-size {192 | 200 | 256 |
1024}
TDM-PW-
Profile
Defines the number of payload bytes per packet. Valid
only if service type = unstructured or unstructured
octet-aligned. Valid choices depend on the TDM
service as follows.
192: DS1
200: DS1, required only if unstructured octet-aligned
service is supported
256: E1
1024: DS3 / E3
no payload-size
Deletes the configured payload size.
