Dasan V5808 - Protocol Type Configuration; TDM Service Configuration (CES UNI); Expected Circuit Pack Type

User Manual UMN:CLI
V5808
733
12.4.6.5 Protocol Type Configuration
To perform the configuration for protocol type-based service that is offered from an IP
host, use the following command.
Command
Mode
Description
udp port PORT tos TOS
Traffic-VoIP
Specifies the port number that offers the
UDP/TCP/TLSP/protocol-type service and the value of
the TOS field of the IPv4 header.
PORT: port number
TOS: type of service per IETF RFC 1349 or a
differentiated services code point (DSCP) defined by
IANA (default: 0)
protocol { udp | tcp | tlsp | TYPE}
port PORT tos TOS
12.4.7 TDM Service Configuration (CES UNI)
This section describes the configuration of CES UNI in the ONT where the physical path
terminates and physical level functions are performed.
In order to configure CES UNI and TDM service, you need to specify the CES port first.
To specify the CES port, use the following command.
Command
Mode
Description
ces PORT
Traffic-
Profile
Specifies the CES port.
PORT: CES port number (1 to 8)
no ces PORT
Deletes the CES port configuration.
After opening CES Configuration mode, the prompt changes from SWITCH(config-traffic-
pf[NAME])# to SWITCH(config-traffic-pf[NAME]-ces[PORT])#.
12.4.7.1 Expected Circuit Pack Type
To specify the expected circuit pack type, use the following command.
Command
Mode
Description
expected-type { auto | ds1 | e1 |
c-ds1-e1 | VALUE }
Traffic-CES
Specifies the expected circuit pack type.
auto: Autosense
ds1: DS1
e1: E1
c-ds1-e1: Configurable DS1/E1
VALUE: 1 to 254 (according to "Table 9.1.5-1 – Circuit
pack types" in "ITU-T G.984.4")
