UMN:CLI User Manual
V5808
732
To specify the impedance for the POTS UNI, use the following command.
impedance {600 | 900 | 750 | 820 |
1050}
Specifies the impedance for the specified POTS UNI.
600: 600 Ohm (default)
900: 900 Ohm
750: C1=150 nF, R1=750 Ohm, R2=270 Ohm
820: C1=115 nF, R1=820 Ohm, R2=220 Ohm
1050: C1=230 nF, R1=1050 Ohm, R2=320 Ohm
Deletes the configured impedance for the POTS UNI.
To specify the on-hook transmission type, use the following command.
transmission-path {full-time |
part-time}
Allows setting the POTS UNI either to full-time on-hook
transmission or part-time on-hook transmission.
(default: full-time)
Deletes the configured on-hook transmission type.
To specify Rx/Tx gain value for the receive/transmit signal, use the following command.
Specifies Rx/Tx gain value for the receive/transmit
signal.
VALUE: –120 (–12.0 dB) to 60 (+6.0 dB) (form: two's
complement number, default: 0)
To specify POTS holdover time, use the following command.
pots-holdover-time <0-65535>
Determines the time during which POTS loop voltage is
held up when the ONT is not ranged on the PON. After
the specified time elapses, the ONT drops loop voltage,
and may thereby cause premises intrusion alarm
circuits to go active. When the ONT ranges
successfully on the PON, it restores POTS loop voltage
immediately and resets the timer to zero.
0-65535: POTS holdover time (unit: second, default:
0(= ONT vendor's factory policy))
