User Manual UMN:CLI
V5808
273
To disable double tagging, use the following command
vlan dot1q-tunnel disable
PORTS
Disables the qinq port.
PORTS: qinq port to be disabled
When you configure Double tagging on the V5808, consider the below attention list.
• DT and HTLS cannot be configured at the same time. (If switch should operate as
DT, HTSL has to be disabled.)
• TPID value of all ports on switch is same.
• Access Port should be configured as Untagged, and Uplink port as Tagged.
• Ignore all tag information of port which comes from untagged port (Access Port).
• Port with DT function should be able to configure Jumbo function also
8.1.9.8 Inner Tag Configuration
To put the configured C-VLAN tag in the inner tag field of incoming untagged packet on a
port, use the following command.
vlan dot1q-tunnel ingress push
c-vid PORTS <1-4094>
Puts the configured C-VLAN tag in the inner tag field of
incoming packet on an ingress port
no vlan dot1q-tunnel ingress
push c-vid PORTS
Disables the C-VLAN inner tagging on an ingress port.
To remove the C-VLAN inner tag from the outgoing packet on a port, use the following
command.
vlan dot1q-tunnel egress pop c-
vid PORTS
Removes C-VLAN inner tag from the outgoing packet
on an egress port
no vlan dot1q-tunnel egress pop
c-vid PORTS
Disables the C-VLAN inner tag removal on an egress
port.
8.1.9.9 Displaying VLAN Mapping and Translation
To display the configured VLAN mapping and translation, use the following command.
show vlan dot1q-tunnel {ingress
| egress} mapping [PORTS]
Shows the configured VLAN mapping.
Shows the status of UNI/NNI ports.
