Dasan V5808 - Loopback

User Manual UMN:CLI
V5808
655
video | wifi} UNI-PORTs {enable |
disable}
ONU-ID: ONU ID (1 to 128) or ONU serial number
eth/pots/ces/virtual-eth/Video: Ethernet / POTS / CES /
virtual Ethernet/Video/Wi-Fi
UNI-PORT: UNI port number
To see the admin status of the ONU (ONT) UNI, use show onu uni-status command.
(See 12.2.25 Displaying ONU Information)
12.2.4 Forward Error Correction (FEC) Mode
To enable/disable FEC mode for ONU ID, use the following command.
Command
Mode
Description
onu us-fec-mode ONU-IDs
enable
GPON-OLT
Enables upstream FEC mode for ONU ID.
onu us-fec-mode ONU-IDs
disable
Disables upstream FEC mode for ONU ID.
If you want to enable the upstream FEC mode for ONU, you should enable upstream
FEC mode for OLT first. For the detail of how to enable the upstream FEC mode for OLT,
see 12.1.6 Forward Error Correction (FEC) Mode.
12.2.5 Loopback
To enable/disable the loopback for UNI of ONU, use the following command.
Command
Mode
Description
onu loopback ONU-IDs uni eth
UNI-PORTs {enable type 3 |
disable}
GPON-OLT
Enables/disables the loopback for the specified
Ethernet (type 3) UNI port of ONU.
ONU-IDs: ONU ID (1 to 128) or ONU serial number
UNI-PORTs: UNI port number
onu loopback ONU-IDs uni ces
UNI-PORTs {enable type <1-5> |
disable}
Enables/disables the loopback for the specified
CES/TDM UNI port of ONU.
ONU-IDs: ONU ID (1 to 128) or ONU serial number
UNI-PORTs: UNI port number
1: payload loopback
2: line loopback
3: OpS-directed loopback 1 (loopback from/to PON
side)
4: OpS-directed loopback 2 (loopback from/to CES UNI
side)
5: OpS-directed loopback 3 (loopback of both PON
i
i
