UMN:CLI User Manual
V5808
666
NAME single-tagged-frame
TABLE treat inner vid {<0-4094> |
copy-inner } cos {<0-7> | copy-
inner | dscp-to-pbit}
profile to ONU ID and configures the inner tag
treatment for filtered single-tagged frames.
onu extended-vlan ONU-ID
NAME untagged-frame TABLE
treat inner vid <0-4094> cos
{<0-7> | dscp-to-pbit}
Associates the extended VLAN tagging operation
profile to ONU ID and configures the inner tag
treatment for filtered untagged frames.
no onu extended-vlan ONU-ID
NAME { double-tagged-frame |
single-tagged-frame | untagged-
tagged-frame }
Removed the extended VLAN tagging operation profile
association from ONU ID and the configured inner tag
treatment.
For the details of how to create and configure the extended VLAN tagging operation
profile, see 12.6 Extended VLAN Tagging Operation Profile.
12.2.20 ONU RateLimit Configuration
To enable Network Address Translation (NAT) mode of ONU, use the following command.
Command
Mode
Description
onu nat-mode ONU_IDs {enable |
disblae}
GPON-OLT
Enables NAT mode of ONU.
ONU_ID: ONU ID or ONU serial number.
no onu nat-mode [ONU_IDs]
Configures the Not use the NAT mode function.
To configure the upstream/downstream traffic for GEM port of ONU, use the following
command.
Command
Mode
Description
onu rate-limit ONU_ID mapper
MAPPER_ID gemport
GEMPORT_RANGE {upstream |
downstream} PIR_VALUE
GPON-OLT
Sets the down/upstream traffic for GEM port of ONU.
ONU_ID: ONU ID or ONU Serial Number
MAPPER_ID: 802.1p mapper ID (1-32)
GEMPORT_RANGE: gem port
PIR_VALUE: PIR (Bandwidth in steps of 64Kbps)
To configure the rate limit profile for GEM port of ONU, use the following command.
Command
Mode
Description
onu rate-limit ONU_ID mapper
MAPPER_ID gemport
GEMPORT_RANGE profile
PROF_NAME
GPON-OLT
Sets the rate limit profile for GEM port of ONU.
PROF_NAME: profile name
To display the information of NAT mode and rate-limit, use the following command.
Command
Mode
Description
