User Manual UMN:CLI
V5808
739
stage-13: Randomizer stage 13 preload (Bit 0)
12.4.11 Creating a GEM Port Network CTP
The GEM port Network CTP profile manages the upstream traffic identified by the GEM
Port-ID. Each GEM port is identified by a port ID uniquely. The port ID ranges from 0 to 32.
A GEM port ID is unique per GPON interface and represents a specific traffic or group of
flows between the OLT and the ONT. When each GEM port carries the traffic flows, traffic
control is performed according to the specific service profile.
To create a GEM port network CTP for a specified traffic profile, use the following
command.
Creates a GEM port network CTP profile associated
with GEM port ID.
GEM_PORT_ID: 1 to 32, GEM port number
no gemport-nctp GEM_PORT_ID
Removes the created GEM port Network CTP from the
traffic profile
After opening GEM Port Network CTP Service Configuration mode, the prompt changes
from SWITCH(config-traffic-pf[NAME])# to SWITCH(config-traffic-pf[NAME]-gem[ID])#.
To connect a service profile (MAC bridge, IP Host config, video return path service) with a
GEM Port ID, use the following command.
service {bridge | ip-host | video-
return-path} SVC_ID
Specifies a service profile to be mapped to the GEM
port network CTP for traffic management.
bridge: MAC bridge
ip-host: IP Host config
video-return-path: video return path service
SVC_ID: service ID
12.4.12 Saving Traffic Profile
To save the traffic profile after configuring a traffic profile, use the following command.
Saves a traffic profile configuration.
Whenever you modify a traffic profile, you should apply the changes again using the
apply command. If you do not, it will not be applied.
