User Manual UMN:CLI
V5808
775
12.9.3 Jitter Buffer Desired Depth
To specify the desired nominal fill depth of the playout buffer in the PSN to TDM direction,
use the following command.
jitter-buffer-desired-depth
VALUE
Specifies the desired nominal fill depth of the playout
buffer in the PSN to TDM direction.
VALUE: expressed as a multiple of the 125 μs frame
rate
no jitter-buffer-desired-depth
Deletes the configured nominal fill depth of the playout
buffer.
12.9.4 Fill Policy
To specify the payload bit pattern to be applied toward the TDM service, if no payload
packet is available to play out, use the following command.
fill-policy {vendor-specific |
play-out-ais | play-out-all-1s |
play-out-all-0s | repeat-prev-data
| play-out-ds1-idle}
Defines the payload bit pattern to be applied toward the
TDM service if no payload packet is available to play
out.
vendor-specific: ONT default, vendor-specific
(recommended: AIS for unstructured service, all 1s for
structured service)
play-out-ais: Play out AIS according to the service
definition (for example, DS3 AIS)
play-out-all-1s: Play out all 1s
play-out-all-0s: Play out all 0s
repeat-prev-data: Repeat the previous data
play-out-ds1-idle: Play out DS1 idle (Appendix C of "b-
ATIS T1.403")
Deletes the configured payload bit pattern.
12.9.5 Alarm-related Policy
The supports four pairs of alarm-related policies configuration which causes the
corresponding alarm to be declared or cleared. To configure the policy (anomaly rate) that
causes the alarm to be declared or cleared, use the following command.
buffer-over-underrun-
declaration-policy <1-100>
Defines the anomaly rate that causes the
corresponding alarm to be declared. If this density of
anomalies occurs during the alarm onset soak interval,
the alarm is declared.
buffer-over-underrun: buffer overrun/underrun
loss-packet: loss packet
loss-packet-declaration-policy
<1-100>
malformed-packet-declaration-
policy <1-100>
