To configure the treatment of filtered double-tagged frames, use the following command.
treat {remove {single | double} |
discard-frame}
Configures the treatment of filtered double-tagged
frames.
remove single: removes one tag (the outer tag is
stripped from double-tagged frames.)
remove double: removes all of outer and inner tags.
discard-frame: drops the frames.
treat inner vid {<0-4094> | copy-
inner | copy-outer} cos {<0-7> |
copy-inner | copy-outer | dscp-
to-pbit} tpid {output dei {0 | 1 |
copy-inner | copy-outer} | copy-
inner | copy-outer | 0x8100}
Configures the inner tag treatment for filtered double-
tagged frames.
0-4094: uses this value as the VID in the inner VLAN
tag.
copy-inner: copies value from inner tag of received
frame.
copy-outer: copies value from outer tag of received
frame.
0-7: uses this value as the priority in the inner VLAN
tag.
treat outer vid {<0-4094> | copy-
inner | copy-outer} cos {<0-7> |
copy-inner | copy-outer | dscp-
to-pbit} tpid {output dei {0 | 1 |
copy-inner | copy-outer} | copy-
inner | copy-outer | 0x8100}
Configures the outer tag treatment for filtered double-
tagged frames.
no treat {remove-discard | outer
| inner}
Deletes the treatment-related configuration above.
12.6.1.3 Configuration for Untagged Frame Treatment
To create the mapping table to configure the untagged frame treatment, use the following
command.
Creates the mapping table to configure the untagged
frame treatment.
TABLE: table number
Deletes the specified table.
After opening (creating) the mapping table to configure the untagged frame treatment, the
prompt changes from SWITCH(config-ext-vlan-oper[NAME])# to SWITCH(config-ext-vlan-
oper[NAME]-untagged-frame[TABLE])#.
