12.6.1.2 Configuration for Double-tagged Frame Treatment
To create the mapping table to configure the double-tagged frame treatment, use the
following command.
double-tagged-frame TABLE
Creates the mapping table to configure the double-
tagged frame treatment.
TABLE: table number
no double-tagged-frame TABLE
Deletes the specified table.
After opening (creating) the mapping table to configure the double-tagged frame
treatment, the prompt changes from SWITCH(config-ext-vlan-oper[NAME])# to
SWITCH(config-ext-vlan-oper[NAME]-double-tagged-frame[TABLE])#.
To configure the filtering for double-tagged frames, use the following command.
filter inner vid {any | <0-4094>}
cos {any | <0-7>} tpid {any |
0x8100 | input [dei {0 | 1}]}
Configures the received double-tagged frames to be
filtered by the provided values concerning inner tag.
vid any: do not filter on the inner VID.
vid 0-4094: filters received frames on this value.
cos any: do not filter on the inner priority.
cos 0-7: filters received frames on this value.
tpid any: do not filter on the inner TPID field.
tpid 0x8100: filters received frames on this value.
tpid input: input TPID attribute value, don't care about
DE bit.
tpid input dei 0: input TPID, DE=0
tpid input dei 1: input TPID, DE=1
filter outer vid {any | <0-4094>}
cos {any | <0-7>} tpid {any |
0x8100 | input [dei {0 | 1}]}
Configures the received double-tagged frames to be
filtered by the provided values concerning outer tag.
no filter {inner | outer}
Deletes the filtering configuration above.
