User Manual UMN:CLI
V5808
635
to RF signal.
To specify the destination MAC address, ethertype, and VLAN ID for the head-end node
on the connection to send RF return path traffic, use the following command.
onu rf-pw dst-mac MACADDR
Sets the destination MAC address of RF return path
modulator’s FPGA.
onu rf-pw ethtype TYPE-NUM
Sets the ethernet type and VLAN ID for RF return path
traffic forwarding.
TYPE-NUM: ethernet type (e.g. 0x8864 - PPPoE)
To delete the configured parameters for the head-end node on the connection, use the
following command.
Deletes the configured destination MAC address,
ethernet type or VLAN ID for the head-end node
connection.
This feature is available for DASAN Network Solutions’ RF return modulator (V5800) only.
The V5808 is not provide compatibility with other RF return modulators.
To display the configured parameters for the head-end node, use the following command.
Enable
Global
GPON
GPON-OLT
Shows the configured parameters for the head-end
node to send the RF return path traffic.
12.1.13 Downstream Traffic Control
The V5808 provides the function to control the downstream traffic based on MAC address
and VLAN ID by each OLT. Basically, the OLT system creates MAC table through MAC
learning with the incoming traffic from ONU, and transmits the downstream traffic to GEM
port with the MAC table information. However, V5808 can control this downstream traffic
with MAC address and VLAN ID by user configuration.
To configure the downstream traffic control, use the following command.
olt ds-gem-mapping {mac | mac-
vid | vid | per-flow [key-mac| key-
mac-vid]}
Configures the GEM port mapping mode.
mac, mac-vid: GEM port mapping with destination
MAC address or destination MAC address and VLAN
ID
vid: GEM port mapping with VLAN ID
(default: mac)
onu vlan-gem-mapping ONU-ID
Maps GEM port of ONU and VLAN ID.
