12.7.1.6 DTMF Digit Configuration
To configure DTMF digit power levels, use the following command.
Command
Mode
Description
dtmf-digit levels VALUE
VoIP-Profile
Specifies the power level of DTMF digits that may be
generated by the ONT toward the subscriber set. It is a
2s complement value referred to 1mW at the 0TLP
(dBm0), with resolution 1dB.
VALUE: DTMF digit power level
no dtmf-digit levels
Deletes the configured DTMF digit power levels.
To configure DTMF digit duration, use the following command.
Command
Mode
Description
dtmf-digit duration VALUE
VoIP-Profile
Specifies the duration of DTMF digits that may be
generated by the ONT toward the subscriber set.
VALUE: DTMF digit duration (unit: ms)
no dtmf-digit duration
Deletes the configured DTMF digit duration.
12.7.1.7 Hook Flash Time Configuration
To configure hook flash time, use the following command.
Command
Mode
Description
hook-flash-time {max | min}
VALUE
VoIP-Profile
Defines the maximum or minimum duration recognized
by the ONT as a switchhook flash.
VALUE: maximum or minimum hook flash time (unit:
ms)
no hook-flash-time {max | min}
Deletes the configured hook flash time.
12.7.1.8 VoIP Extended Operation Configuration
To configure the special line service, use the following command.
Command
Mode
Description
special-line-service disable
VoIP-Profile
Disables the special line service.
special-line-service hot-line
NUMBER
Enables the hot-line feature that it immediately dials a
pre-configured number as soon as the handset goes
off hook.
special-line-service warm-line
timeout <1-30> NUMBER
Enables the warm-line feature that it dials a pre-
configured number if no digits were entered before the
specified timer value expired when the handset went
off hook.
1-30: warm-line timeout value (unit: seconds)
