UMN:CLI User Manual
V5808
710
to a specified VID with tag.
1-4094: VLAN ID
0-7: CoS value
uni eth UNI-PORT vlan-
operation ds-oper {keep |
remove}
Sets the policy of VLAN tagging for downstream frame.
keep: keeps forwarding the incoming tagged frame
from OLT to UNI.
remove: removes a tag from the incoming tagged
packet and forwards it to UNI.
no uni eth UNI-PORT vlan-
operation us-oper
Deletes the configured policy of VLAN tagging
operation.
no uni eth UNI-PORT vlan-
operation ds-oper
12.3.3.2 Max Host
To configure the maximum number of hosts for a MAC bridge ID, use the following
command.
bridge BRIDGE-ID max-hosts <0-
255>
Sets the maximum number of hosts that can connect to
the specified MAC bridge ID.
BRIDGE-ID: MAC bridge ID
0-255: the maximum number of hosts (0: unlimited)
12.3.3.3 Rate Limit
To configure the rate limit for downstream traffic of an ONU, use the following command.
uni eth UNI-PORT rate-limit
downstream PIR_BANDWIDTH
[SIR_BANDWIDTH]
Sets the downstream traffic bandwidth for UNI port.
SIR_BANDWIDTH: 0 to 2147483584 (in steps of
64Kbps)
PIR_BANDWIDTH: 0 to 2147483584
no uni eth UNI-PORT rate-limit
Deletes the configured rate limit
12.3.3.4 IGMP Group List
You can configure the maximum number of multicast groups that a host on a port can join.
To specify the maximum number of IGMP groups per UNI-side port, use the following
command.
uni eth UNI-PORT igmp max-
groups <0-255>
Specifies the maximum number of IGMP groups for a
port.
UNI-PORT: UNI port number
0-255: number of IGMP groups (default: 16)
no uni eth UNI-PORT igmp max-
groups
Deletes a specified maximum number of IGMP groups.
