Dasan V5808 - Saving Multicast Profile; Applying Multicast Profile

UMN:CLI User Manual
V5808
786
Command
Mode
Description
igmp immediate-leave disable
Multicast-
Profile
Deletes a specified IGMP configuration
no igmp robustness-variable
no igmp querier address
no igmp querier query-interval
no igmp querier max-response-time
no igmp {access-list | static-access-list} all
no igmp access-list vid {untagged | VLANS}
dst-ip start A.B.C.D end A.B.C.D [bw VALUE |
src-ip A.B.C.D | gem PORTS]
no igmp static-access-list vid {untagged |
VLANS} dst-ip start A.B.C.D end A.B.C.D [bw
VALUE | src-ip A.B.C.D | gem PORTS]
no igmp tag-control
no igmp ds-tag-control
no igmp upstream rate-limit
12.11.3 Saving Multicast Profile
After configuring a multicast profile, you need to save the profile with the following
command.
Command
Mode
Description
apply
Multicast-Profile
Saves a multicast profile configuration.
Whenever you modify a multicast profile, you should apply the changes again using the
apply command. If you do not, it will not be applied.
12.11.4 Applying Multicast Profile
If you want to apply a created multicast profile to a MAC bridge service profile, open
Traffic Profile Configuration mode first, then you have to apply the multicast profile to
MAC bridge service profile and its UNI-side port.
SWITCH(config-mcast-profile[TEST])# apply
SWITCH(config-mcast-profile[TEST])# exit
SWITCH(gpon)# traffic-profile 1 create
SWITCH(config-traffic-pf[1])# bridge 1
SWITCH(config-traffic-pf[1]-bridge[1])# uni eth 1
SWITCH(config-traffic-pf[1]-bridge[1]-uni[eth:1])# multicast-profile TEST
To apply the configured multicast profile to a specified UNI-side port of a traffic profile,
use the following command.
