V5808
719
mac-filter {ip4-mcast | ip6-mcast|
ip4-bcast | rarp | ipx | net-beui |
apple-talk | bridge-manage | arp |
pppoe}
Traffic
Bridge-ANI
Enables the MAC filtering function according to the
protocol type for ANI-side bridge port.
no mac-filter {ip4-mcast | ip6-
mcast| ip4-bcast | rarp | ipx | net-
beui | apple-talk | bridge-manage
| arp | pppoe}
Disables the MAC filtering function according to the
protocol type for ANI-side bridge port.
The following table shows ten attributes that permit the OLT to specify whether MAC
address or Ethertypes of the given type are forwarded or filtered. In each case, the initial
value of the attribute is 0.
Protocol
MAC Address
Ethertype
IPv4 multicast
01.00.5E.00.00.00 – 01.00.5E.7F.FF.FF
–
IPv6 multicast
33.33.00.00.00.00 –33.33.FF.FF.FF.FF
–
IPv4 broadcast
FF.FF.FF.FF.FF.FF
0x0800
RARP
FF.FF.FF.FF.FF.FF
0x8035
IPX
FF.FF.FF.FF.FF.FF
0x8137
09.00.1B.FF.FF.FF, 09.00.4E.00.00.02
–
NetBEUI
03.00.00.00.00.01
–
AppleTalk
FF.FF.FF.FF.FF.FF
0x809B, 0x80F3
09.00.07.00.00.00 – 09.00.07.00.00.FC,
09.00.07.FF.FF.FF
–
Bridge management
information
01.80.C2.00.00.00 – 01.80.C2.00.00.FF
–
ARP
FF.FF.FF.FF.FF.FF
0x0806
PPPoE broadcast
FF.FF.FF.FF.FF.FF
0x8863
Tab. 12.2 Protocol Types for MAC Filtering
12.4.3.6 UNI Port Configuration
A UNI-side port is an ONU device port connected to a subscriber. To enable/disable a
connection between a MAC bridge service profile and UNI-side port for the downstream
traffic, use the following command.
Command
Mode
Description
uni {eth | virtual-eth} UNI-PORT
Traffic
Bridge
Connects an UNI port of ONT to a specified MAC
bridge service profile.
UNI-PORT: UNI port number
no uni {eth | virtual-eth} UNI-
PORT
Removes the UNI port of ONT from the MAC bridge
service profile.
VLAN Tagging Filtering
To enable/disable VLAN tagging filtering function on the UNI-side port, use the following
