Dasan V5808 - OMCC Monitoring

User Manual UMN:CLI
V5808
641
olt ber ds-interval <1000-10000>
[olt ber sd-threshold <4-9>] [olt
ber sf-threshold <3-8>] [olt ber
us-interval <1000-10000>]
GPON-OLT
Specifies the monitor direction and interval of the bit
error ratio.
ds-interval: Downstream BER interval from OLT to
ONU
us-interval: Upstream BER interval from ONU to OLT
1000-10000: downstream BER interval value (default:
5000ms)
1000-10000: upstream BER interval value (default:
2000ms)
olt ber us-interval <1000-10000>
[olt ber ds-interval <1000-
10000>] [olt ber sd-threshold <4-
9>] [olt ber sf-threshold <3-8>]
olt ber sd-threshold <4-9> [olt
ber ds-interval <1000-10000>]
[olt ber us-interval <1000-
10000>] [olt ber sf-threshold <3-
8>]
Sets the threshold for reporting of signal degrade (SD)
BER or signal fail (SF) BER alarms.
4-9: SD threshold value (default: 8)
3-8: SF threshold value (default: 7)
olt ber sf-threshold <3-8> [olt
ber ds-interval <1000-10000>]
[olt ber us-interval <1000-
10000>] [olt ber sd-threshold <4-
9>]
To display the information of OLT Bit Error Ratio (BER), use the following command.
Command
Mode
Description
show olt ber [OLT-ID]
Enable
Global
GPON
Shows OLT’s Bit Error Ratio (BER) configuration
(including upstream/downstream BER interval and
threshold).
show olt ber
GPON-OLT
12.1.18 OMCC Monitoring
If an error occurs on the ONT Management and Control Channel (OMCC), the OLT
attemps to recover from an error and the ONUs are deactivated by the OLT until the
OMCC is recovered.
To enable/disable the OMCC recovery monitoring function with ONU deactivation process,
use the following command.
Command
Mode
Description
olt omcc-recovery enable
GPON-OLT
Enables the OMCC recovery monitoring function with
ONU deactivation process.
olt omcc-recovery threshold <5-
720>
Sets the threshold limit for OMCC recovery attempts.
5-720: the number of times OLT can atttemp to retry
OMCC recovery (default: 5)
olt omcc-recovery mode
deactivation
Sends the deactivation PLOAM when OLT detects the
OMCC problem.
