User Manual UMN:CLI
V5808
277
SWITCH(bridge)# vlan pvid 5/2,6/2 51
SWITCH(bridge)# vlan pvid t/1-t/16 1
SWITCH(bridge)# show vlan
Sample Configuration 2: Deleting Port-based VLAN
The following is deleting br3 among configured VLAN.
SWITCH(bridge)# vlan del br3 3
SWITCH(bridge)# exit
SWITCH(config)# interface br3
SWITCH(interface)# shutdown
SWITCH(interface)# exit
SWITCH(config)# bridge
SWITCH(bridge)# no vlan br3
SWITCH(bridge)# show vlan
u: untagged port, t: tagged port
-----------------------------------------------------------------
| 1 2 3 4
Name( VID| FID) |123456789012345678901234567890123456789012
-----------------------------------------------------------------
default( 1| 1) |u...uuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuuu
br2( 2| 2) |.u........................................
br4( 4| 4) |...u......................................
SWITCH(bridge)#
Sample Configuration 3: Configuring QinQ
Port 10 of SWITCH 1 and port 11 of SWITCH 2 are connected to the network where
different VLANs are configured. To communicate without changing VLAN configuration of
SWITCH 1 and SWITCH 2 which communicate with PVID 10, configure it as follows.
You should configure the ports connected to network communicating with PVID 11 as
Tagged VLAN port.
< SWITCH 1 >
SWITCH(bridge)# vlan dot1q-tunnel enable 10
SWITCH(bridge)# vlan pvid 10 11
SWITCH(bridge)# show vlan dot1q-tunnel
Tag Protocol Id : 0x8100 (d: double-tagging port)
----------------------------------------------------
| 1 2 3 4
Port |123456789012345678901234567890123456789012
----------------------------------------------------
dtag .........d................................
SWITCH(bridge)#
< SWITCH 2 >
SWITCH(bridge)# vlan dot1q-tunnel enable 11
SWITCH(bridge)# vlan pvid 11 11
To Next Page
