UMN:CLI User Manual
V5808
674
onu cfm ONU_ID mip level LEVEL vlan
VLANS
Specifies a MIP and its level on the VLAN ID.
ONU_ID: ONU ID (1 to128) or ONU serial
number
LEVEL: MIP’s level (0 to 7)
VLAN: VLAN list (maximum 12)
no onu cfm ONU_ID mip [level LEVEL]
Removes the configured MIP.
To specify the ONU ID and bridge’s UNI Ethernet port or ANI mapper to which the MEP is
attached, use the following command.
onu cfm ONU_ID mep { uni eth PORT |
ani mapper PORT } mep-id MEP_ID
ccm { enable | disable }
Enables/disables the continuity check messages
(CCMs) exchange and specifies an ONU ID and
MEP ID.
ONU-ID: ONU ID (1 to128) or ONU serial
number
PORT: ONU’s UNI Ethernet port number or ANI
mapper port number
MEP_ID: MEP ID (1 to 8191)
onu cfm ONU_ID mep { uni eth PORT |
ani mapper PORT } mep-id MEP_ID
primary-vlan VLANS peer-mep-id ID
ma <1-65535>
Configures a MEP on the ONU ID and assigns a
remote MEP ID and primary VLAN ID.
MEP_ID: MEP ID (1 to 8191)
VLANS: primary VLAN ID
ID: remote MEP ID (1 to 8191)
1-65535: MA index
no onu cfm ONU_ID mep [{uni eth
PORT | ani mapper PORT} [mep-id
MEP_ID]]
Removes the configured MEP ID from ONU.
Ethernet Loopback function supports fault verification through Loopback Messages (LBM)
and Loopback Reply (LBR). These messages are used during initial set-up or after a fault
has been detected to verify that the fault has occurred between two end points. CFM
OAM allows both unicast and multicast loopback. Ethernet Traceroute function is used to
retrieve adjacency relationship between a MEP and a remote MEP or MIP. And it is also
used for fault localization. The sends LinkTrace Message (LTM) frames to discover a
path for a link trace.
To configure the source / destination MEP to send the LoopBack Message (LBM) or
LinkTrace message (LTM), use the following command.
onu cfm test loopback ONU_ID mep
{ uni eth PORT | ani mapper PORT }
mep-id MEP_ID {rmep-id <1-8191> |
rmac MACADDR} [count NUMBER]
Performs the Loopback/Traceroute test for ONU
and specifies MEP ID and remote MEP ID/ MAC
address to send LBM/LTM from the ONU.
ONU_ID: ONU ID (1 to128) or ONU serial number
PORT: ONU’s UNI Ethernet port number or ANI
mapper port number
onu cfm test traceroute ONU_ID
mep { uni eth PORT | ani mapper
