User Manual UMN:CLI

V5808

741

To display the VLAN filter configured on the specific Traffic profile, use the following

command.

Command

Mode

Description

show traffic-profile NAME vlan-

filter

Enable

Global

GPON

GPON-OLT

Shows the VLAN filter configured on the specified

Traffic profile.

NAME: Traffic profile name

12.4.15 Sample Configuration

For the sample configuration, see “Configuration Example 1” in 12.15 Sample

Configuration.
