12.2.26.4 ONU Profile & IP Host Configuration (Step3)
The following command lines show a sample config for OLT port corresponding to the
sample scheme above.
OLT(gpon)# show running-config
...
onu-profile ONU create
traffic-profile TRAFFIC
apply
!
...
OLT(config-gpon-olt[2])# show running-config gpon-olt 2
gpon-olt 2
olt auto-to-manual enable
olt anti-spoofing enable expire-timeout 60
discover-serial-number start 10
onu add 2 DSNW4bd68b38 auto-learning
onu-profile 2 ONU
onu static-ip 2 ip-host 1 10.45.33.11/16 gw 10.45.1.254
onu static-ip 2 ip-host 2 200.1.1.1/24 gw 200.1.1.254
onu voip-sip 2 phone-number pots 1 07070177670
onu voip-sip 2 auth pots 1 07070177670 39588102947
Create an ONU profile (ONU). And then configure the corresponding settings. Here,
associate the created traffic profile (TRAFFIC) to this profile (ONU).
Register an ONT (DSNW4bd68b38) to the OLT with specifying its ID (2).
Apply the created ONU profile (ONU) to the specified ONT (OLT port: 2, ONU ID: 2).
Assign the planned static IP addresses to the configured IP hosts (ip-host 1 for
POTS, and ip-host 2 for LAN1 port on sample config in this guide). Here, ip-host
1 uses network 10.45.x.x, and ip-host 2 uses 200.1.1.x.
To assign static IP address to the IP hosts, ip address static should be set in
ip-host-config of traffic profile first.
The ip-host 1 is a host only for VoIP, and the ip-host 2 is a host only for non-
omci-configured interfaces.
If you want to have the VoIP host assigned the same IP as NAT host, you should
perform the following: All of the POTS interfaces have to be set to non-omci (mgmt-
mode uni pots 1 non-omci and mgmt-mode uni pots 2 non-omci). This
tells an IP host binding. The non-omci-configured interfaces are all affected by ip-
host 2.
You can check whether the IP hosts are assigned IP addresses normally and VoIP
service is registered normally with the following commands.
OLT(config-gpon-olt[2])# show onu ip-host 2
---------------------------------------------------------------
OLT : 2, ONU : 2, Host : 1(0x0001)
---------------------------------------------------------------
IP Option : Static
