Cisco Catalyst 4500 Series Software Configuration Guide

43-24
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 43 Configuring VRF-lite
Configuring VRF-lite for IPv6
This example shows how to populate VRF with a static route:
Switch(config)# ipv6 route vrf v6a 7000::/64 TenGigabitEthernet3/2 4000::2
Routing Protocols
OSPFv3
To configure the OSPFv3 router process and the IPv6 address family in OSPFv3, perform the following
steps:
This example shows how configure the OSPFv3 router process:
Switch(config-router)# router ospfv3 1
Switch(config-router)# router-id 1.1.1.1
Switch(config-router)# address-family ipv6 unicast
Switch(config-router-af)# exit-address-family
To enable OSPFv3 on an interface, do the following:
Command Purpose
Step 1
Switch> enable
Enters privileged EXEC mode.
Enter your password if prompted.
Step 2
Switch# configure terminal
Enters global configuration mode.
Step 3
Switch(config)# router ospfv3
process-id
Enables OSPFv3 router configuration mode for the IPv4
or IPv6 address family.
Step 4
Switch(config-router)# area area-ID
[default-cot | nssa | stub]
Configures the OSPFv3 area.
Step 5
Switch(config-router)# router-id
router-id
Use a fixed router ID.
Step 6
Switch(config-router)#
address-family ipv6 unicast vrf
vrf-name
Or
Switch(config-router)#
address-family ipv4 unicast
Enters IPv6 address family configuration mode for
OSPFv3 in VRF vrf-name
or
Enters IPv4 address family configuration mode for
OSPFv3.
Step 7
Switch(config-router)# redistribute
source-protocol [process-id] options
Redistributes IPv6 and IPv4 routes from one routing
domain into another routing domain.
Step 8
Switch(config-router)# end
Returns to privileged EXEC mode.
Command Purpose
Step 1
Switch> enable
Enters privileged EXEC mode.
Enter your password if prompted.
Step 2
Switch# configure terminal
Enters global configuration mode.
Step 3
Switch(config)# interface
type-number
Specifies an interface type and number, and places the
switch in interface configuration mode.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
