Chapter 49 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
Per-User ACL and Filter-ID ACL
Prior to Cisco IOS Release 12.2(52)SG, the Catalyst 4500 platform only supported downloadable ACLs, which work with the
Cisco ACS server but not with third-party AAA servers. With
Cisco IOS Release 12.2(52)SG, the Catalyst 4500 switch offers the Filter-ID/Per-user-acl enhancement, which allows ACL
policy enforcement using a third-party AAA server.
The Filter-ID feature provides the following capabilities:
Filter-ID option allows an administrator to define the ACL name on the AAA server using IETF standard RADIUS
attribute. The ACL itself must be preconfigured locally on the switch.
The Per-user-acl feature provides the following capabilities:
Per-user ACL allows an administrator to define the per-user ACL on the AAA server using Cisco RADIUS AV pairs. This
action allows a third-party AAA server to interoperate by loading the Cisco RADIUS dictionary, which has Cisco Radius
AV pairs configured as a VSA.
Note The RADIUS vendor-specific attributes (VSAs) allow vendors to support their own proprietary RADIUS attributes that
are not included in standard RADIUS attributes.
Configuring the Switch
To configure the switch for per-user ACL and filter-ID ACL:
Step 1 Configure the IP device tracking table.
Switch(config)# ip device tracking
Step 2 Configure static ACL for the interface.
Switch(config)# int g2/9
Switch(config-if)# ip access-group pacl-4 in
Interface Configuration Example
Switch# show running-configuration interface g2/9
Building configuration...
Current configuration : 617 bytes
!
interface GigabitEthernet2/9
switchport
switchport access vlan 29
switchport mode access
switchport voice vlan 1234
access-group mode prefer port
ip access-group pacl-4 in
speed 100
duplex full
authentication event fail action authorize vlan 111
authentication event server dead action authorize vlan 333
authentication event server alive action reinitialize
authentication host-mode multi-auth
authentication order dot1x
authentication port-control auto
authentication timer restart 100
authentication timer reauthenticate 20
