IEEE 802.3az Energy Efficient Ethernet
For more details, see the URL:
http://www.cisco.com/en/US/prod/collateral/switches/ps5718/ps4324/white_paper_c11-676336.pdf
Sections include:
• Determining EEE Capability, page 14-24
• Enabling EEE, page 14-24
• Determining EEE Status, page 14-24
Determining EEE Capability
To determine whether a line card supports EEE, use the show interface capabilities module module
command, as follows:
Switch# show interface capabilities module 3
GigabitEthernet3/1
Model: WS-X4748-NGPOE+E-RJ-45
Type: 10/100/1000-TX
Speed: 10,100,1000,auto
Duplex: half,full,auto
Auto-MDIX: yes
EEE: yes ( 100-Tx and 1000-T auto mode )
Enabling EEE
To enable EEE on a given port, use the power efficient-ethernet auto command.
The following example shows how to enable EEE:
Switch# config t
Switch(config)# interface gigabitethernet 1/1
Switch(config-if)# power efficient-ethernet auto
Switch(config-if)# exit
Determining EEE Status
To determine EEE status use the show platform software interface interface status command:
The following example determines EEE status:
Switch(config)# show platform software interface g2/1 status
Switch Phyport Gi2/1 Software Status
EEE: Disabled
Command Purpose
Step 1
Switch# configure terminal Enters configuration mode.
Step 2
Switch(config)# interface interface
Enters interface configuration mode and
specifies the port to be configured.
Step 3
Switch(config-if)# power efficient-ethernet auto
Enables EEE.
Step 4
Switch(config-if)# exit Exits global configuration mode.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
