Cisco Catalyst 4500 Series Software Configuration Guide

9
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS
Chapter 9 Configuring Interfaces
Deploying 10-Gigabit Ethernet and Gigabit Ethernet SFP Ports on Supervisor
The output for the show idprom tengigabitethernet slot/interface command displays the contents of both the SFP+ and the
OneX Convertor module SEEPROMs when an SFP+ in a OneX Convertor module is plugged into an X2 port.
Deploying 10-Gigabit Ethernet and Gigabit Ethernet SFP Ports on
Supervisor Engine V-10GE
Note On a Catalyst 4510R series switch, if you enable both the 10-Gigabit Ethernet and Gigabit Ethernet SFP
uplink ports, you must reboot the switch. On the Catalyst 4503, 4506, and 4507R series switches, this
capability is automatically enabled.
Prior to Cisco IOS Release 12.2(25)SG, you could enable either the dual wire-speed 10-Gigabit Ethernet ports or four
alternatively wired Gigabit Ethernet SFP uplink ports.
Beginning with Cisco IOS Release 12.2(25)SG, you could simultaneously deploy the dual 10-Gigabit Ethernet ports and the
four Gigabit Ethernet SFP ports on the Catalyst 4503, Catalyst 4506, and Catalyst 4507R chassis.
When you deploy a Catalyst 4510R chassis, one of the following configurations is supported:
• Dual 10-Gigabit Ethernet ports (X2 optics) only.
• Four Gigabit Ethernet ports (SFP optics) only.
• Both the dual 10-Gigabit Ethernet and the four Gigabit Ethernet ports. The tenth slot (Flex-Slot) only supports a 2-port
gigabit interface converter (GBIC) line card (WS-X4302-GB) when in this mode.
• You cannot place a line card with a backplane traffic capacity exceeding 6 Gbps in slots 8, 9, and 10 of a Catalyst 4510R-E
chassis when used with a Supervisor Engine 6-E or 6L-E.
To select the 10-Gigabit Ethernet or the Gigabit Ethernet SFP uplink port, perform this task:
The following example shows how to enable both 10-Gigabit Ethernet and Gigabit Ethernet SFP uplink ports on a Catalyst
4510R series switch:
Switch# configure terminal
Switch(config)# hw-module uplink select all
Warning: This configuration mode will place slot 10 in flex slot mode
Note When you modify the uplink mode, you must reboot the switch.
Command Purpose
Step 1
Switch# configure terminal
Establishes global configuration mode.
Step 2
Switch(config)# hw-module uplink select [all |
gigabitethernet | tengigabitethernet]
Selects the port type to enable.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
