Cisco Catalyst 4500 Series Software Configuration Guide

75-2
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 75 Configuring Ethernet OAM and CFM
About Ethernet CFM
• About Ethernet OAM Protocol, page 75-33
• Enabling and Configuring Ethernet OAM, page 75-35
• Displaying Ethernet OAM Protocol Information, page 75-49
• Ethernet CFM and Ethernet OAM Interaction, page 75-51
About Ethernet CFM
Ethernet CFM is an end-to-end per-service-instance (per-VLAN) Ethernet layer OAM protocol. It
includes proactive connectivity monitoring, fault verification, and fault isolation. End-to-end can be
provider-edge-to provider-edge (PE-to-PE) device or customer-edge-to-customer-edge (CE-to-CE)
device. Ethernet CFM, as specified by IEEE 802.1ag, is the standard for Layer 2 ping, Layer 2 traceroute,
and end-to-end connectivity verification of the Ethernet network.
These sections contain conceptual information about Ethernet CFM:
• Ethernet CFM and OAM Definitions, page 75-2
• CFM Domain, page 75-3
• Maintenance Associations and Maintenance Points, page 75-4
• CFM Messages, page 75-5
• Crosscheck Function and Static Remote MEPs, page 75-5
• SNMP Traps and Fault Alarms, page 75-5
• Configuration Error List, page 75-6
• IP SLAs Support for CFM, page 75-6
Ethernet CFM and OAM Definitions
The following table describes many of the terms in this chapter that are related to OAM and CFM
features:
Term Definition
CC Continuity Check
CFM Connectivity Fault Management
EI Ethernet Infrastructure or EVC Infrastructure
EVC Ethernet Virtual Circuit
MEP Maintenance Endpoint
MIP Maintenance Intermediate Point
OAM Operations Administration and Maintenance
UNI User to Network Interface
