Cisco Catalyst 4500 Series Software Configuration Guide

14-15
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 14 Environmental Monitoring and Power Management
Power Management
Special Considerations for the 4200 W AC and 6000 W AC Power Supplies
The 4200 W AC and 6000 W AC power supply has two inputs: each can be powered at 110 or 220 V.
The 9000 W AC power supply has three inputs: each can be powered at 110 or 220V.
The output of the show power command for the 4200 W AC, 6000 W AC, and 9000W AC power
supplies are similar to that of 1400 W DC triple-input power supply (that is, the status of the submodules
(multiple inputs) is displayed). With these power supplies, you can distinguish submodule “failed”
versus “off,” and the status of the submodules (good, bad, or off):
Switch# show power
Power Fan Inline
Supply Model No Type Status Sensor Status
------ ---------------- --------- ----------- ------- -------
PS1 PWR-C45-4200ACV AC 4200W good good good
PS1-1 220V good
PS1-2 off
PS2 PWR-C45-4200ACV AC 4200W bad/off good bad/off
PS2-1 220V good
PS2-2 220V bad
Power supplies needed by system : 1
Power supplies currently available : 2
Power Summary Maximum
(in Watts) Used Available
---------------------- ---- ---------
System Power (12V) 140 1360
Inline Power (-50V) 0 1850
Backplane Power (3.3V) 0 40
---------------------- ---- ---------
Total 140 (not to exceed Total Maximum Available = 2100)
Switch#
Switch# show power
Power Fan Inline
Supply Model No Type Status Sensor Status
------ ---------------- --------- ----------- ------- -------
PS1 PWR-C45-9000ACV AC 9000W good good good
1400 W AC Chassis = 1360
PoE = 0
6
Chassis = 2473
PoE = 0
9/11
2800 W AC Chassis = 1360
PoE = 1400
Chassis = 2473
PoE = 2333
Chassis
7
—9/11
PoE
8
—2/3
1. Chassis power includes power for the supervisor engine(s), all line cards, and the fan tray.
2. The efficiency for the 1400 W DC power supply is 0.75, and 0.96 is applied to PoE.
3. DC input can vary for the 1400 W DC power supply and is configurable. For more information, see “Special Considerations
for the 1400 W DC Power Supply” on page 21.
4. Not available for PoE.
5. Not available for PoE.
6. No voice power.
7. Data-only.
8. Inline power.
Table 14-5 Available Power for Switch Power Supplies (continued)
Power Supply Redundant Mode (W) Combined Mode (W) Sharing Ratio

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
