Page #548 background image
13-16
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 13 Configuring Cisco NSF with SSO Supervisor Engine Redundancy
Configuring NSF with SSO Supervisor Engine Redundancy
L1 NSF ACK requested:FALSE
L1 NSF CSNP requested:FALSE
NSF L2 Restart state:Running
NSF p2p Restart retransmissions:0
Maximum L2 NSF Restart retransmissions:3
L2 NSF ACK requested:FALSE
Interface:GigabitEthernet2/0/0
NSF L1 Restart state:Running
NSF L1 Restart retransmissions:0
Maximum L1 NSF Restart retransmissions:3
L1 NSF ACK requested:FALSE
L1 NSF CSNP requested:FALSE
NSF L2 Restart state:Running
NSF L2 Restart retransmissions:0
Maximum L2 NSF Restart retransmissions:3
L2 NSF ACK requested:FALSE
L2 NSF CSNP requested:FALSE
Interface:Loopback1
NSF L1 Restart state:Running
NSF L1 Restart retransmissions:0
Maximum L1 NSF Restart retransmissions:3
L1 NSF ACK requested:FALSE
L1 NSF CSNP requested:FALSE
NSF L2 Restart state:Running
NSF L2 Restart retransmissions:0
Maximum L2 NSF Restart retransmissions:3
L2 NSF ACK requested:FALSE
L2 NSF CSNP requested:FALSE
Configuring EIGRP NSF
To configure EIGRP NSF, perform this task:
Verifying EIGRP NSF
To verify EIGRP NSF, you must check that the NSF function is configured on the SSO-enabled
networking device. To verify EIGRP NSF, follow these steps:
Step 1 Verify that “nsf” appears in the EIGRP configuration of the SSO-enabled device by entering the
show running-config command:
Switch# show running-config
.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# router eigrp as-number
Enables an EIGRP routing process, which places
the switch in router configuration mode.
Step 3
Switch(config-router)# nsf
Enables EIGRP NSF.
Use this command on the “restarting” switch and
all of its peers.
