Cisco Catalyst 4500 Series Software Configuration Guide

3-2
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 3 Configuring the Switch for the First Time
Configuring DHCP-Based Autoconfiguration
Configuring DHCP-Based Autoconfiguration
These sections describe how to configure DHCP-based autoconfiguration:
• About DHCP-Based Autoconfiguration, page 3-2
• DHCP Client Request Process, page 3-3
• Configuring the DHCP Server, page 3-4
• Configuring the TFTP Server, page 3-4
• Configuring the DNS Server, page 3-5
• Configuring the Relay Device, page 3-5
• Obtaining Configuration Files, page 3-6
• Example Configuration, page 3-7
If your DHCP server is a Cisco device, or if you are configuring the switch as a DHCP server, refer to
the “IP Addressing and Services” section in the Cisco IOS IP and IP Routing Configuration Guide for
Cisco IOS Release 12.1 for additional information about configuring DHCP.
About DHCP-Based Autoconfiguration
Note Beginning with Release 12.2(20)EW, you can enable DHCP AutoConfiguration by entering the write
erase command. This command clears the startup-config in NVRAM. In images prior to Release
12.2(20)EW, this command does not enable autoconfiguration.
DHCP provides configuration information to Internet hosts and internetworking devices. This protocol
consists of two components: one component for delivering configuration parameters from a DHCP
server to a device and another component that is a mechanism for allocating network addresses to
devices. DHCP is built on a client-server model, in which designated DHCP servers allocate network
addresses and deliver configuration parameters to dynamically configured devices. The switch can act
as both a DHCP client and a DHCP server.
With DHCP-based autoconfiguration, no DHCP client-side configuration is needed on your switch
because your switch (the DHCP client) is automatically configured at startup with IP address
information and a configuration file. However, you need to configure the DHCP server or the DHCP
server feature on your switch for various lease options associated with IP addresses. If you are using
DHCP to relay the configuration file location on the network, you might also need to configure a Trivial
File Transfer Protocol (TFTP) server and a Domain Name System (DNS) server.
DHCP-based autoconfiguration replaces the BOOTP client functionality on your switch.
Passwords No passwords are configured for normal mode or enable mode
(press the Return key)
Switch prompt
Switch>
Interfaces Enabled, with speed and flow control autonegotiated, and without
IP addresses
Table 3-1 Default Switch Configuration (continued)
Feature Default Settings

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
