Chapter 21 Configuring SmartPort Macros
Configuring Static SmartPort Macros
Applying Static SmartPort Macros
To apply a static SmartPort macro, perform these steps, beginning in privileged EXEC mode:
Command Purpose
Step 1
show parser macro
Displays the Cisco-default static SmartPort macros embedded in the
switch software.
Step 2
show parser macro name macro-name
Displays the specific macro that you want to apply.
Step 3
configure terminal
Enters global configuration mode.
Step 4
macro global {apply | trace}
macro-name [parameter {value}]
[
parameter {value}] [parameter
{
value}]
Applies each individual command defined in the macro to the switch by
entering macro global apply macro-name. Specify macro global trace
macro-name to apply and to debug a macro to find any syntax or
configuration errors.
Append the macro with the required values by using the parameter
value keywords. Keywords that begin with $ require a unique parameter
value.
Use the macro global apply macro-name ? command to display a list of
any required values for the macro. If you apply a macro without entering
the keyword values, the commands are invalid and are not applied.
(Optional) Specify unique parameter values that are specific to the
switch. You can enter up to three keyword-value pairs. Parameter
keyword matching is case sensitive. The corresponding value replaces
all matching occurrences of the keyword.
Step 5
interface interface-id
(Optional) Enters interface configuration mode, and specify the
interface on which to apply the macro.
Step 6
default interface interface-id
(Optional) Clears all configuration from the specified interface.
Step 7
macro {apply | trace} macro-name
[parameter {value}] [parameter
{
value}] [parameter {value}]
Applies each individual command defined in the macro to the port by
entering macro global apply macro-name. Specify macro global trace
macro-name to apply and to debug a macro to find any syntax or
configuration errors.
Append the macro with the required values by using the parameter
value keywords. Keywords that begin with $ require a unique parameter
value.
Use the macro global apply macro-name ? command to display a list of
any required values for the macro. If you apply a macro without entering
the keyword values, the commands are invalid and are not applied.
(Optional) Specify unique parameter values that are specific to the
switch. You can enter up to three keyword-value pairs. Parameter
keyword matching is case sensitive. The corresponding value replaces
all matching occurrences of the keyword.
Step 8
end
Returns to privileged EXEC mode.
Step 9
show running-config interface
interface-id
Verifies that the macro is applied to an interface.
Step 10
copy running-config startup-config
(Optional) Saves your entries in the configuration file.
