Cisco Catalyst 4500 Series Software Configuration Guide

5-30
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 5 Configuring Virtual Switching Systems
Configuring a VSS
Dual-Active Detection Restrictions and Guidelines
When configuring dual-active detection, note the following guidelines and restrictions:
• For line redundancy, we recommend configuring at least two ports per switch for dual-active
detection. For module redundancy, the two ports can be on different modules in each switch, and
should be on different modules than the VSL ports, if feasible.
• Only trusted PAgP channels are relied upon to detect dual-active mode of operation.
Configuring a VSS
These sections describe how to configure a VSS:
• Configuring Easy VSS, page 5-30
• Converting to a VSS, page 5-32
• Converting to Quad-Supervisor VSS, page 5-37
• Displaying VSS Information, page 5-39
• Converting a VSS to Standalone Switch, page 5-41
• Configuring VSS Parameters, page 5-42
• Configuring Multichassis EtherChannels, page 5-48
• Configuring Dual-Active Detection, page 5-52
Configuring Easy VSS
Beginning with Cisco IOS XE 3.6.0E (IOS 15.2(2)E), the Catalyst 4500 series switch supports Easy
VSS, which enables you to configure VSS with a single command on the active switch and no action on
the VSS standby switch.
The active switch can gather information from all switches that are Layer 3 reachable.
Note Quad-Supervisor VSS mode is not supported with Easy VSS.
Note Both switches are directly connected to each other using Layer 3 physical interfaces and are reachable
through these interfaces. These physical interfaces are candidate VSL interfaces and are displayed in a
list of "potential" VSL interfaces in the output of the vsl ? command in easy-vss mode. This output also
displays a list of indirectly-reachable Layer 3 interfaces.
Cisco IOS XE 3.6.0E (IOS 15.2(2)E) only supports reachability using a default route. Management and
user-created VRF are not supported.
Note Switches are reachable to each other through management interfaces. Reachability to neighboring
switches using a management interface isn't supported although the management interface appears in the
candidate VSL list.
