Cisco Catalyst 4500 Series Software Configuration Guide

17-5
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 17 Configuring VLANs, VTP, and VMPS
VLANs
Note Catalyst 4500 series switches do not support Token Ring or FDDI media. The switch does not forward
FDDI, FDDI-NET, TrCRF, or TrBRF traffic, but it does propagate the VLAN configuration by using
VTP. The software reserves parameters for these media types, but they are not supported.
Configuring VLANs
Note Before you configure VLANs, you must use VLAN Trunking Protocol (VTP) to maintain global VLAN
configuration information for your network. For complete information on VTP, see the “VLAN Trunking
Protocol” section on page 7.
Note VLANs support a number of parameters that are not discussed in detail in this section. For complete
information, refer to the command reference guide.
Note The VLAN configuration is stored in the vlan.dat file, which is stored in nonvolatile memory. You can
cause inconsistency in the VLAN database if you manually delete the vlan.dat file. If you want to
modify the VLAN configuration or VTP, use the commands described in the following sections and in
the command reference guide.
The following sections describe how to configure VLANs:
• Configuring VLANs in Global Configuration Mode, page 17-5
• Assigning a Layer 2 LAN Interface to a VLAN, page 17-7
Configuring VLANs in Global Configuration Mode
If the switch is in VTP server or transparent mode (see the “VLAN Trunking Protocol” section on
page 17-7), you can configure VLANs in global and VLAN configuration modes. When you configure
VLANs in global and config-vlan configuration modes, the VLAN configuration is saved in the vlan.dat
files, not the running-config or startup-config files. To display the VLAN configuration, enter the show
vlan command.
If the switch is in VLAN transparent mode, use the copy running-config startup-config command to
save the VLAN configuration to the startup-config file. After you save the running configuration as the
startup configuration, the show running-config and show startup-config commands display the VLAN
configuration.
Translational bridge 1 1002 0–1005
Translational bridge 2 1003 0–1005
VLAN state active active; suspend; shutdown
Table 17-2 Ethernet VLAN Defaults and Ranges (continued)
Parameter Default Valid Values

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
