Cisco Catalyst 4500 Series Software Configuration Guide

19-7
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 19 Configuring Layer 2 Ethernet Interfaces
Configuring Ethernet Interfaces for Layer 2 Switching
This example shows how to verify the trunk configuration:
Switch# show interfaces fastethernet 5/8 trunk
Port Mode Encapsulation Status Native vlan
Fa5/8 desirable n-802.1q trunking 1
Port Vlans allowed on trunk
Fa5/8 1-1005
Port Vlans allowed and active in management domain
Fa5/8 1-6,10,20,50,100,152,200,300,303-305,349-351,400,500,521,524,570,801-8
02,850,917,999,1002-1005
Port Vlans in spanning tree forwarding state and not pruned
Fa5/8 1-6,10,20,50,100,152,200,300,303-305,349-351,400,500,521,524,570,801-8
02,850,917,999,1002-1005
Switch#
Configuring an Interface as a Layer 2 Access Port
Note If you assign an interface to a VLAN that does not exist, the interface is not operational until you create
the VLAN in the VLAN database (see the “Configuring VLANs in Global Configuration Mode” section
on page 17-5).
To configure an interface as a Layer 2 access port, perform this task:
Command Purpose
Step 1
Switch(config)# interface {fastethernet |
gigabitethernet | tengigabitethernet}
slot/port
Specifies the interface to configure.
Step 2
Switch(config-if)# shutdown
(Optional) Shuts down the interface to prevent traffic flow until
configuration is complete.
Step 3
Switch(config-if)# switchport
Configures the interface for Layer 2 switching:
• You must enter the switchport command once without any
keywords to configure the interface as a Layer 2 port before
you can enter additional switchport commands with
keywords.
• Required only if you previously entered the no switchport
command for the interface.
Step 4
Switch(config-if)# switchport mode access
Configures the interface as a Layer 2 access port.
Step 5
Switch(config-if)# switchport access vlan
vlan_num
Places the interface in a VLAN.
Step 6
Switch(config-if)# no shutdown
Activates the interface. (Required only if you had shut down the
interface.)
Step 7
Switch(config-if)# end
Exits interface configuration mode.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
