Cisco Catalyst 4500 Series Software Configuration Guide

66-9
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 66 Configuring SPAN and RSPAN
Configuring SPAN
Configuring SPAN Destinations
To configure the destination for a SPAN session, perform this task:
Note SPAN is limited to one destination port per session.
This example shows how to configure interface Fast Ethernet 5/48 as the destination for SPAN session 1:
Switch(config)# monitor session 1 destination interface fastethernet 5/48
Monitoring Source VLANs on a Trunk Interface
To monitor specific VLANs when the SPAN source is a trunk interface, perform this task:
This example shows how to monitor VLANs 1 through 5 and VLAN 9 when the SPAN source is a trunk
interface:
Switch(config)# monitor session 2 filter vlan 1 - 5 , 9
Command Purpose
Switch(config)# [no] monitor session
<session_number> destination interface
<interface> [encapsulation {dot1q}] [ingress
[vlan vlan_IDs] [learning}]
Specifies the SPAN session number (1 through
6) and the destination interfaces or VLANs.
For session_number, specifies the session
number identified with this RSPAN session
(1 through 6).
For interface, specifies the destination
interface.
For vlan_IDs, specifies the destination VLAN.
Use the no keyword to restore the defaults.
Command Purpose
Switch(config)# [no] monitor session
{session_number} filter {vlan vlan_IDs
[, | - ]} | {packet-type {good |
bad}} | {address-type {unicast |
multicast | broadcast} [rx | tx |
both]}
Monitors specific VLANs when the SPAN source is a
trunk interface. The filter keyword restricts
monitoring to traffic that is on the specified VLANs; it
is typically used when monitoring a trunk interface.
For session_number, specifies the session number
identified with this RSPAN session (1 through 6).
For vlan_IDs, specifies the VLAN.
Monitoring is established through all the ports in the
specified VLANs
Use the no keyword to restore the defaults.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
