Cisco Catalyst 4500 Series Software Configuration Guide

49-76
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 49 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
To enable 802.1X with VLAN assignment, perform this task:
The following example shows how to configure MDA on an interface and 802.1X as the authentication mechanism:
Switch(config)# interface FastEthernet3/3
Switch(config-if)# switchport access vlan 10
Switch(config-if)# switchport mode access
Switch(config-if)# switchport voice vlan 16
Switch(config-if)# authentication host-mode multi-domain
Switch(config-if)# authentication port-control auto
Switch(config-if)# dot1x pae authenticator
Switch(config-if)# end
Note You must configure VLAN assignment in the ACS server. No configuration changes are required on the switch.
Cisco ACS Configuration for VLAN Assignment
The procedure for enabling MDA with voice VLAN assignment is the same as that for activating MDA except for one step:
Configure a VLAN for dynamic VLAN assignment after selecting
User > IETF RADIUS Attributes (Figure 49-16). This step ensures correct functioning of the ACS configuration required for
dynamic VLAN assignment.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# interface
interface-id
Enters interface configuration mode.
Step 3
Switch(config-if)# switchport
access vlan-id
Sets the VLAN for a switched interface in access mode.
Step 4
Switch(config-if)# switchport mode
access
Specifies a nontrunking, nontagged single VLAN Layer 2 interface.
Step 5
Switch(config-if)# switchport voice
vlan vlan-id
Sets the voice VLAN for the interface.
Step 6
Switch(config-if)# authentication
host-mode multi-domain
Enables MDA on the interface.
Step 7
Switch(config-if)# authentication
port-control auto
Enables 802.1X authentication on the interface.
Step 8
Switch(config-if)# dot1x pae
authenticator
Enables 802.1X authentication on the port with default parameters.
Refer to the “Default 802.1X Configuration” section on page 49-27.
Step 9
Switch(config)# end
Returns to privileged EXEC mode.
Step 10
Switch# show dot1x interface
interface-id details
(Optional) Verifies your entries.
Step 11
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
