Cisco Catalyst 4500 Series Software Configuration Guide

54-6
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 54 Auto Identity
Configuration Examples for Auto Identity
Configuring Auto Identity at an Interface Level
When you configure two interface templates, you must configure the merge keyword. If you do not, the
last configured template is used.
Configuration Examples for Auto Identity
• Example: Configuring Auto Identity Globally, page 54-7
• Example: Configuring Auto Identity at an Interface Level, page 54-7
Step 7
Switch(config-radius-server)# key ipv4
{0 string | 7 string} string
Specifies the authentication and encryption key for all RADIUS
communications between the device and the RADIUS server.
Note This command is not a part of the global template, and
you must configure it.
Step 8
Switch(config-radius-server)# end
Exits RADIUS server configuration mode and returns to privileged
EXEC mode.
Command or Action Purpose
Command or Action Purpose
Step 1
Switch# enable
Enables privileged EXEC mode.
• Enter your password if prompted.
Step 2
Switch# configure terminal
Enters global configuration mode.
Step 3
Switch(config)# interface type number
Configures an interface and enters interface configuration mode.
Step 4
Switch(config-if)# source template
{AI_CLOSED_MODE | AI_LOW_IMPACT_MODE |
AI_MONITOR_MODE | template-name} [merge]
Configures a source template for the interface.
Step 5
Switch(config-if)# source template
{AI_CLOSED_MODE | AI_LOW_IMPACT_MODE |
AI_MONITOR_MODE | template-name} [merge]
(Optional) Configures a source template for the interface and
merges this template with the previously configured template.
• When you configure two templates, if you do not configure
the merge keyword, the last configured template is used.
Step 6
Switch(config-if)# switchport access vlan
vlan-id
Sets the VLAN when the interface is in access mode.
Step 7
Switch(config-if)# switchport voice vlan
vlan-id
Configures a voice VLAN on a multiple VLAN access port.
Step 8
Repeat Steps 4, 6, and 7 on all interfaces that
must have the Auto Identity feature configured.
—
Step 9
Switch(config-if)# end
Exits interface configuration mode and returns to privileged
EXEC mode.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
