Cisco Catalyst 4500 Series Software Configuration Guide

CHAPTER
44-1
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
44
Configuring Quality of Service
This chapter describes how to configure quality of service (QoS) with either automatic QoS (auto-QoS)
commands or standard QoS commands on a Catalyst 4500 series switch. It describes how to specify QoS
configuration on different types of interfaces (access, Layer 2 trunk, Layer 3 routed, Etherchannel) as
well as VLANs. It also describes how to specify different QoS configurations on different VLANs on a
given interface (per-port per-VLAN QoS).
A switch supports a QoS configuration model known as MQC (Modular QoS CLI). Please refer to the
appropriate configuration section for the supervisor engine on which QoS will be configured. For more
information about MQC, see the “Modular Quality of Service Command-Line Interface" section of the
Cisco IOS Quality of Service Solutions Configuration Guide, Release 12.3.
This chapter addresses both VSS and non-VSS environments. Sections include:
• Overview of QoS, page 44-1
• Configuring VSS QoS, page 44-13
• Configuring QoS on a Standalone Supervisor Engine 6-E/6L-E or Supervisor Engine 7-E/7L-E/8-E,
page 44-47
• Configuring VSS Auto-QoS, page 44-81
• Configuring Auto-QoS on a Standalone Supervisor Engine 6-E/6L-E or Supervisor Engine
7-E/7L-E/8-E, page 44-88
Note For complete syntax and usage information for the switch commands used in this chapter, see the
Cisco IOS Command Reference Guides for the Catalyst 4500 Series Switch.
If a command is not in the Cisco Catalyst 4500 Series Switch Command Reference , you can locate it in
the Cisco IOS Master Command List, All Releases.
Overview of QoS
Typically, networks operate on a best-effort delivery basis, which means that all traffic has equal priority
and an equal chance of being delivered in a timely manner. When congestion occurs, all traffic has an
equal chance of being dropped.
QoS selects network traffic (both unicast and multicast), prioritizes it according to its relative
importance, and uses congestion avoidance to provide priority-indexed treatment; QoS can also limit the
bandwidth used by network traffic. QoS can make network performance more predictable and bandwidth
utilization more effective.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
