Cisco Catalyst 4500 Series Software Configuration Guide

9
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS
Chapter 9 Configuring Interfaces
Configuring Optional Interface Features
This example shows how to allow the Multigigabit Ethernet interface 3/1 to autonegotiate the speed and duplex mode:
Switch(config)# interface gigabitethernet 3/1
Switch(config-if)# speed auto
This example shows how to limit speed negotiation to 2.5G on the Multigigabit Ethernet interface 3/1:
Switch(config)# interface gigabitethernet 3/1
Switch(config-if)# speed auto 2500
This example shows how to enable downshift on the Multigigabit Ethernet interface 3/1:
Switch(config)# interface gigabitethernet 3/1
Switch(config-if)# speed auto
Switch(config-if)# no disable downshift
Setting the Interface Duplex Mode
Note When the interface is set to 1000 Mbps, you cannot change the duplex mode from full duplex to half
duplex.
To set the duplex mode of a Fast Ethernet interface, perform this task:
This example shows how to set the interface duplex mode to full on Fast Ethernet interface 5/4:
Switch(config)# interface fastethernet 5/4
Switch(config-if)# duplex full
Displaying the Interface Speed and Duplex Mode Configuration
To display the interface speed and duplex mode configuration for an interface, enter this command:
Command Purpose
Step 1
Switch(config)# interface fastethernet
slot/interface
Specifies the interface to be configured.
Step 2
Switch(config-if)# duplex [auto | full | half]
Sets the duplex mode of the interface.
Command Purpose
Switch# show interfaces [fastethernet |
gigabitethernet | tengigabitethernet]
slot/interface
Displays the interface speed and duplex mode
configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
