Chapter 44 Configuring Quality of Service
Configuring VSS QoS
For a standalone supervisor engine, you must reboot the engine after applying this command.
For redundant supervisors in SSO mode, you must enter the redundancy reload shelf command enforce
reboot to both the supervisors. For redundancy supervisors in RPR mode, you must execute two
consecutive switchovers to enforce the system queue limit on both the supervisors.
This example shows how to set the queue limit globally to 1024 on a standalone supervisor engine:
Switch> enable
Switch# configure terminal
Switch(config)# hw-module system max-queue-limit 1024
Switch(config)# exit
Switch# reload (for standalone supervisors)
Switch# redundancy reload shelf (for redundancy supervisors in SSO mode)
or
Switch# redundancy force-switchover (followed by another redundancy force-switchover, for
redundancy supervisors in RPR mode)
Configuring VSS QoS
Note HQoS is not supported on the Catalyst 4500 series switch.
Topics include:
• MQC-based QoS Configuration, page 44-48
• Platform-supported Classification Criteria and QoS Features, page 44-48
• Platform Hardware Capabilities, page 44-49
• Prerequisites for Applying a QoS Service Policy, page 44-49
• Restrictions for Applying a QoS Service Policy, page 44-50
• Classification, page 44-50
• Policing, page 44-51
• Marking Network Traffic, page 44-52
• Shaping, Sharing (Bandwidth), Priority Queuing, Queue-limiting and DBL, page 44-59
• Enabling Per-Port Per-VLAN QoS, page 44-70
• Applying Flow-based QoS Policy, page 44-75
• Configuring CoS Mutation, page 44-79
• Configuring System Queue Limit, page 44-80
MQC-based QoS Configuration
Note Starting with Cisco IOS Release 12.2(40)SG, a Catalyst 4900M, a Catalyst 4948E, or a Catalyst 4500
series switch with Supervisor Engine 6-E or Supervisor Engine 6L-E use the MQC model of QoS.
To apply QoS, you use the Modular QoS Command-Line Interface (MQC), which is a CLI structure that
allows you to complete the following tasks:
